The AD539 is a low distortion analog multiplier having two identical signal channels (Y1 and Y2), with a common X input providing linear control of gain. Excellent ac characteristics up to video frequencies and a −3 dB bandwidth of over 60 MHz.
The AD539 is a low‑distortion, wideband dual‑channel analog multiplier/divider offering 2‑quadrant multiplication/division and two independent signal channels. It provides a signal bandwidth of up to 60 MHz and a linear control channel bandwidth of 5 MHz, making it suitable for high‑speed AGC, VCA, voltage‑controlled filters, video processing, and automatic signal‑leveling applications.
The device is supplied in several package options, including hermetic ceramic SBDIP (D‑16), low‑cost PDIP (N‑16), and LCC (E‑20‑1), with an S‑grade version qualified for military temperature ranges. Power consumption is only 135 mW at the recommended +5 V supply.
| Maximum Output Voltage (Vx) | 0 V to 3 V |
|---|---|
| Power Consumption | 135 mW |
| Number of Signal Channels | 2 |
| Package Options | Hermetic ceramic SBDIP (D‑16), low‑cost PDIP (N‑16), LCC (E‑20‑1), MIL‑STD‑883 |
The device consumes only 135 mW when powered from the recommended +5 V supply.
It has two independent signal channels.
The AD539 is offered in hermetic ceramic SBDIP (D‑16), low‑cost PDIP (N‑16), LCC (E‑20‑1), and a MIL‑STD‑883 version.
