This document is an instruction manual for a small Hozokiri (a type of woodworking tool), which provides information on the performance parameters and usage precautions of the product.
This manual explains safe handling of the Makita 5500S plunge saw, including grounding requirements, personal protective equipment, and warnings about improper use. It also details the tool's main functions, power requirements, and dimensions.
Maintenance procedures such as inspecting and replacing carbon brushes, lubricating moving parts, and contacting authorized service centers are covered, along with after‑sales service locations and contact numbers. This manual is written in Japanese.
| Motor type | 直巻整流子電動機 |
|---|---|
| Voltage | 単相100ボルト |
| Frequency | 50-60ヘルツ |
| Power consumption | 1420ワット |
| No‑load speed (vertical) | 1.650回転/分 |
| No‑load speed (horizontal) | 2.200回転/分 |
| Maximum vertical cutting depth | 90mm |
| Maximum horizontal cutting width | 68mm |
| Maximum vertical cutting length | 235mm |
| Blade diameter | 180mm |
| Blade opening | 130mm |
| Dimensions (W×D×H) | 幅560mm×奥行620mm×高さ810mm |
| Weight | 68kg |
Use the voltage shown on the nameplate, which is single‑phase 100 V.
