The 170B6 is a high-performance LCD monitor equipped with Perfect Panel, faster response time, dual input signals, and a compact stand for higher efficiency. It also features SmartManage capability and environmentally friendly lead-free design, providing the best overall cost-effectiveness. It meets the ISO 13406-2 Class I standard for zero-defect displays, with a quick 8-microsecond response time for excellent text and image display. The SXGA 1280 x 1024 resolution offers sharper and clearer visuals. It supports both analog VGA and digital DVI signals with dual inputs. It is compatible with SmartManage for network management, and the lead-free design is more environmentally friendly. It has lower power consumption compared to the industry average. The built-in stereo speakers enhance convenience and aesthetics. It is designed for optimal height and angle. It also features USB ports for convenient peripheral connections and an integrated power supply to replace external power supplies.
The Philips 170B6CS is a 17‑inch SXGA LCD monitor featuring a 1280 × 1024 native resolution, 250 nit brightness, and fast 8 ms response time. It offers multiple video inputs (VGA, DVI, composite, component, S‑Video) and built‑in 2 W speakers, with SmartManage network management and an eco‑friendly, lead‑free design.
The manual covers installation, OSD menu navigation, power settings, and compliance information such as Energy Star, CE, FCC, and UL certifications. Detailed specifications, dimensions, weight, and environmental operating ranges are also provided. This manual is written in Chinese.
| Panel size | 17 inch |
|---|---|
| Native resolution | 1280 × 1024 |
| Brightness | 250 nit |
| Contrast ratio | 500:1 |
| Viewing angle | 160°/155° |
| Response time | 8 ms |
| Power consumption (typical) | 33 W |
| USB interface | USB 2.0 |
| Dimensions (with base) | 375 × 377 × 210 mm |
| MTBF | 50 000 hours |
| Energy Star compliance | Yes |
| Video inputs | VGA, DVI, Composite, Component, S‑Video |
The monitor supports analog VGA, DVI, composite, component, and S‑Video inputs.
It has a native resolution of 1280 × 1024 pixels and can operate at up to 75 Hz, with a recommended 60 Hz mode.
Typical power consumption is 33 W.
