The Philips 190B6 is a large display monitor designed for high-demand users. It offers superior performance with its large screen and Perfect Panel guarantee. It also supports remote LAN asset management and features a lead-free design. The monitor provides exceptional image quality, featuring a display that meets the ISO 13406-2 Class I standard with no defective pixels and a fast 8-millisecond response time for excellent text and image display. It has a SXGA 1280 x 1024 resolution for sharp and clear visuals, and supports both analog VGA and digital DVI inputs. Additionally, it includes built-in speakers, an independent audio interface for efficient networking conferences, and a design that allows for optimal height and angle adjustments. The monitor is also compatible with SmartManage for network management and features a lead-free design for environmental friendliness. It offers convenient features such as USB ports and a built-in power supply.
This manual describes the Philips 190B6CB 19‑inch SXGA LCD monitor, its features, and how to set it up. It includes details on the PerfectPanel technology, anti‑glare polarizer, and environmental design such as lead‑free construction and Energy Star compliance.
The guide covers specifications, power requirements, mounting options, input connectors (VGA, DVI‑D, USB 2.0, audio), OSD language settings, SmartManage network management, and accessories supplied with the monitor. This manual is written in Japanese.
| Panel size | 19 inch / 48 cm |
|---|---|
| Resolution | 1280 × 1024 @ 75 Hz |
| Brightness | 250 nits |
| Response time | 8 ms |
| Viewing angle | 160° / 160° (horizontal/vertical) |
| Input connectors | VGA, DVI‑D, USB 2.0, 3.5 mm audio |
| Power consumption | 40 W (typical) |
| Weight | 64 kg |
| Tilt range | -5° to +30° |
The monitor provides analog VGA, DVI‑D, USB 2.0, and a 3.5 mm audio input.
The display has an 8 ms response time.
Yes, SmartManage compatibility provides network‑based monitoring and management functions.
It uses an internal power supply that accepts 100‑240 VAC, 50‑60 Hz and consumes about 40 W.
