This is the Ibanez AC119 power adapter user manual
This manual explains how to operate the Ibanez 7th Heaven distortion pedal, including battery replacement, power‑supply options, and safety warnings. It also details each control knob, LED indicator, footswitch, and the various effect modes.
Technical data such as power requirements, dimensions, weight, and current consumption are listed, along with a wiring diagram for safe connections. The document is multilingual but the core operating instructions are presented in English.
| Power supply | 9V battery (S-006P) or AC109, AC309, AC509 adapters |
|---|---|
| Current consumption | 14 mA maximum |
| Dimensions | 125 mm (D) × 75 mm (W) × 53 mm (H) |
| Weight | 460 g (with battery) |
Press the button to open the pedal, release the battery snap, replace the battery, and close the pedal.
Only the Ibanez AC109, AC309, or AC509 adapters should be used.
The LED lights up when the effect is on and dims when the battery is low, indicating the battery should be replaced.
Either switch off the power supply or reduce the volume to the minimum level to prevent damage.
