FASTTRAK SX8300 SATA RAID card is an accessory of Foundertech server. This card is compliant with SATAII standard RAID card, supporting RAID0, 1, 5, 10, 50 and JBOD. Equipped with this SATA RAID card, it can provide better performance and higher data security.
The manual explains how to install the Fasttrak SX8300 SATA RAID card in a server, create the required driver disk, and configure supported operating systems. It also lists hardware specifications and safety notices.
Additional sections cover operating‑system installation steps, common error sources, and detailed FAQ for issues such as interrupt conflicts, Master/Slave drive settings, and migrating RAID arrays to another card. This manual is written in Chinese.
| PCI Interface | 64bit/133MHz PCI‑X |
|---|---|
| Number of Channels | 8 |
| Interface Bandwidth | PCI‑X 64‑bit 133MHz |
| Operating Voltage | +5V ±5% |
| Auxiliary Voltage | 3.3V ±0.3V |
| Physical Dimensions | 19.56 cm × 6.5 cm |
| SATA Connectors | 8 |
| RAID Controller Chip | PDC81731 |
Disable other SATA controllers on the motherboard to free IRQ14 and IRQ15 for the RAID card.
Yes, all Fasttrak SX8300 cards recognize the same RAID array, so the configuration can be transferred after reconnecting the hardware.
