DAT-V5 series AC/DC module power supply with three outputs 30-50W, suitable for industrial, military, aerospace and other fields, the product has CE/EMC certification, with high power density, ultra-thin design, high reliability, shock resistance, multiple protection functions and other features.
This manual describes the electrical characteristics and connection pins of the Dilong DAT‑V5 series, including input voltage, output power, and available DC output levels. It also lists safety standards, cooling methods, and environmental operating ranges.
Technical data such as temperature coefficient, insulation voltage limits, and shock resistance are presented, along with recommended installation practices and compliance information for UL, IEC, and other standards. This manual is written in Chinese.
| Input Voltage | AC 220 V ±20 % |
|---|---|
| Temperature Coefficient | 0.03 %/°C |
| Insulation Voltage (Vin‑Vo) | >1500 VAC |
| Insulation Voltage (Vin‑FG / Vo‑FG) | Vin‑FG >1500 VAC, Vo‑FG >500 VDC |
It accepts AC 220 V with a tolerance of ±20 %.
The temperature coefficient is 0.03 % per °C.
