Key facts
- Manuals
- 6
- Languages
- ZH · JA
- Last added
- 2011-12-23
Featured 石家庄迪龙 manuals
Dilong DAD-V4 Module Power Supply Datasheet
This datasheet describes the technical parameters of the Dilong DAD-V4 series 25 W module power supply, including input voltage ranges, selectable output voltages, accuracy, efficiency, and protection features. It also lists environmental specifications, mechanical dimensions, and pin assignments.
Key features include dual‑output configurations (isolated or common‑ground), high efficiency (>75%), over‑current protection, strong isolation (up to 1500 VAC), and compliance with IEC and UL standards for industrial and military applications. This manual is written in Chinese.
Covers: Technical Parameters · Input and Output Voltage · Efficiency and Power · Protection Features · Environmental Conditions · Mechanical Dimensions
Dilong DAS2.5-■-■ED Module Power Supply Datasheet
The DAS2.5-■-■ED is a compact 2.5 W AC/DC module power supply designed for industrial applications. It features a wide input voltage range, multiple selectable DC output levels, and a high efficiency exceeding 75 %.\n\nKey features include over‑current protection, high isolation resistance, robust shock and temperature ratings, natural air cooling, and a low‑radiation plastic enclosure. The design complies with IEC1000, EN61000, UL1950 and other safety standards, making it suitable for harsh environments and even military‑grade requirements. This manual is written in Chinese.
Covers: Technical Parameters · Input Voltage · Output Voltage · Efficiency · Protection Features · Operating Environment
Dilong DZE3000R Series Power Supply Manual
The Dilong DZE3000R series is a high‑power density, integrated sealed power supply offering up to 3000 W output. It features robust anti‑corrosion, anti‑moisture, and magnetic‑compatible designs for reliable operation in harsh environments.
The document provides detailed electrical parameters, input voltage options, temperature and humidity limits, cooling method, and reliability data such as MTBF, helping users install, operate, and maintain the unit safely. This manual is written in Japanese.
Covers: Technical Parameters · Electrical Characteristics · Operating Conditions · Cooling Method · Reliability (MTBF)
Dilong DAT-V5 Manual
This manual describes the electrical characteristics and connection pins of the Dilong DAT‑V5 series, including input voltage, output power, and available DC output levels. It also lists safety standards, cooling methods, and environmental operating ranges.
Technical data such as temperature coefficient, insulation voltage limits, and shock resistance are presented, along with recommended installation practices and compliance information for UL, IEC, and other standards. This manual is written in Chinese.
Covers: Electrical Connections · Specifications · Performance · Cooling and Safety · Environmental Conditions · Installation Guidelines
Latest 石家庄迪龙 manuals
Dilong DAD-V4 Module Power Supply Datasheet
Datasheet 1 pages · 126 KB · ZHThe Dilong DAD-V4 module power supply datasheet provides specifications for the 25 W AC/DC dual‑output unit.
Dilong DAS2.5-■-■ED Module Power Supply Datasheet
Datasheet 1 pages · 142 KB · ZHThe Dilong DAS2.5-■-■ED module power supply provides 2.5 W AC/DC output with selectable voltages, high efficiency, and extensive protection for industrial use.
Dilong DZE3000R Series Power Supply Manual
User Manual 1 pages · 199 KB · JATechnical manual for the Dilong DZE3000R 3000 W power supply with specifications and operating guidelines.
Dilong DAT-V5 Manual
User Manual 1 pages · 163 KB · ZHThe Dilong DAT‑V5 manual provides specifications, wiring details, and operating guidelines for the series.
Dilong Technology DAD2.5 Dual-Output Module Power Supply Manual
Datasheet 1 pages · 128 KB · ZHThe manual provides specifications and features of the Dilong Technology DAD2.5 dual‑output AC/DC 2.5 W module power supply.
Dilong DZE500S Power Module Datasheet
Datasheet 1 pages · 206 KB · ZHTechnical specifications for the Dilong DZE500S power module, covering input/output ranges, power, efficiency, protection and environmental ratings.
Which document do I need?
Datasheet
Ratings, dimensions and ordering codes, for selection and design work.
User Manual
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Questions answered in 石家庄迪龙 manuals
What protection features are provided?
The unit includes over‑current protection (>120 % of rated current), isolation resistance >100 MΩ, and isolation voltage up to 1500 VAC (or 500 VDC).
What are the operating temperature limits for industrial use?
The device operates from –25 °C to +55 °C in industrial environments.
Which output voltages can be selected on this module?
The module can provide selectable DC outputs of 3.3 V, 5 V, 12 V, 15 V, 24 V, 28 V, 48 V, or 110 V.
What is the maximum output power of the DZE3000R?
The DZE3000R can deliver up to 3000 W of output power.
Which input voltages are supported?
It accepts DC12, DC24, DC28, DC48, DC110, and DC220 inputs.
What input voltage does the DAT‑V5 accept?
It accepts AC 220 V with a tolerance of ±20 %.
From: Dilong DAT-V5 Manual
