This is a repair manual for Samsung LCD monitors released by Samsung Electronics Co., Ltd. It includes disassembly, reassembly, adjustment, adjustment, troubleshooting and other contents.
This manual provides service information for the Samsung NB15AS 152N LCD end board. It includes safety precautions, troubleshooting procedures, and detailed disassembly instructions.
The document also contains the printed board layout, principle diagrams, and panel dimension data to assist technicians in repair and maintenance tasks. This manual is written in Chinese.
| Model | NB15AS 152N |
|---|
The model number is NB15AS 152N.
Section 10 of the manual provides the printed board layout.
