This operating manual provides information on the ASDA-AB series servo drives and ECMA series servo motors. It includes: installation and inspection of servo drives and servo motors, composition description of servo drives, steps of trial operation, introduction and adjustment methods of control functions of servo drives, all parameter descriptions, communication protocol descriptions, testing and maintenance, troubleshooting, and application examples.
This manual is intended for servo system designers, installers, wiring personnel, commissioning engineers, and maintenance staff who work with the Delta ASDA-AB series servo drives and ECMA series servo motors. It covers safety precautions, environmental requirements, and proper handling before the equipment is powered.
The document includes chapters on product inspection, installation, wiring, panel operation, test‑run procedures, control modes, parameter configuration, communication interfaces, and appendices with part numbers and accessories. Detailed wiring diagrams, parameter tables, and troubleshooting guides are provided to ensure reliable and safe operation. This manual is written in Chinese.
| Maximum signal input cable length | 3 m (9.84 ft) |
|---|---|
| Maximum encoder feedback cable length | 20 m (65.62 ft) |
| Minimum separation between power and signal cables | 30 cm (11.8 in) |
