DVP04AD-E2 module is a module of Delta DVP series programmable logic controller. It can receive 4 analog input signals and convert them into 16-bit digital signals. Through the port configuration, you can select voltage input or current input. Through FROM/TO instructions, you can access the data in the module, or you can directly read the average value of channels by using MOV instruction (Please refer to allocation of special registers D9900 ~ D9999).
The DVP04AD-E2 is a 4‑channel analog input module for Delta PLC systems. It converts external voltage or current signals into 16‑bit digital data and supports both voltage (±10 V, ±5 V) and current (±20 mA) input ranges. The module features optical‑coupler isolation, configurable input modes, and built‑in self‑diagnosis.
The manual covers electrical specifications, wiring diagrams, I/O terminal layout, register maps, and configuration procedures. It explains how to use FROM/TO instructions and special registers D9900‑D9999 to read average or present values, adjust offset and gain, and enable limit detection. Installation guidelines emphasize proper grounding, shielding, and environmental conditions.
| Power supply voltage | 24VDC (20.4VDC ~ 28.8VDC) |
|---|---|
| Maximum rated power consumption | 1 W |
| Operating temperature range | 0 °C ~ 55 °C |
| Storage temperature range | -25 °C ~ 70 °C |
| Analog input voltage range | ±10 V, ±5 V |
| Number of analog input channels | 4 channels per module |
| Hardware resolution | 14 bits |
| Input impedance | ≥1 MΩ |
| Isolation voltage (digital circuits to ground) | 500 VDC |
The module requires a 24 VDC supply, with an acceptable range of 20.4 VDC to 28.8 VDC.
It provides four analog input channels per module.
The module provides 500 VDC isolation between digital circuits and ground.
