Delta DVP-SV is a 28-point (16 input + 12 output) PLC MPU, offering various instructions and with 16k steps program memory, able to connect to all DVP-SS/SA/SX/SC/SV series extension models, including digital I/O (max. 512 points), analog modules (for A/D, D/A conversion and temperature measurement) and all kinds of high-speed extension modules. 4 groups of high-speed (200kHz) pulse output and 2 two-axis interpolation instructions satisfy all kinds of applications. DVP-SV is small in size and easy to install.
The DVP‑SV is a 28‑point (16 input + 12 output) PLC with 16 k steps program memory, supporting digital, analog and high‑speed extension modules. It offers high‑speed pulse outputs and two‑axis interpolation for a wide range of automation applications.
This guide covers installation requirements, DIN‑rail or direct mounting, wiring recommendations, power‑supply specifications, battery‑low indication and safety precautions to ensure reliable operation of the controller.
| Power supply voltage | 24VDC (-15% ~ 20%) |
|---|---|
| Inrush current | Max. 2.2A @ 24VDC |
| Fuse capacity | 2.5A/30VDC, Polyswitch |
Use 22‑16 AWG (1.5 mm) single or multiple‑core wire on the I/O wiring terminals.
Secure the PLC to a 35 mm DIN rail using the retaining clip to prevent side‑to‑side movement.
The BAT LOW indicator turns on when the internal battery voltage is low, indicating the battery should be replaced or recharged.
