SMS1103 LCD module is a digital pen bar type LCD module, which can display 11 digits and 11 hint characters and 1 decimal point. It is low-power and widely used in intelligent display instruments.
About this manual
The SMS1103 is a character‑type LCD display module that can show 11 characters, 11 symbols and one decimal point. It operates with low power and connects to a MCU via a three‑wire serial interface.
This manual details the display capacity, electrical specifications, temperature ranges, and pin assignments (VDD, VSS, DI, CLK, CS, BL+). It also includes the pin‑out table for interfacing the module. This manual is written in Chinese.
What's inside
- Display Capacity
- Electrical Specifications
- Temperature Range
- Pin Definitions
- Interface
- Operating Instructions
