This is an operation manual for the SR 80 series controller
This manual explains the operation of the Shimaden SR80 controller, covering basic display screens, panel indicators, and the sequence of settings required to configure the device. It includes a detailed description of terminal assignments, power‑on procedures, and the flow of operation pages used to adjust parameters.
Key sections describe input signal types, output adjustment characteristics, automatic calculation mode, secondary setting behavior, communication interfaces, error message meanings, and troubleshooting steps. The document also provides tables for terminal layout, panel display symbols, and parameter limits for each function. This manual is written in Japanese.
