Key facts
- Brand
- Sensaphone
- Model
- SCADA 3000
- Industry
- Industrial
- Documents
- 2
- Languages
- EN
- Last added
- 2026-10-22
Start here
Sensaphone SCADA 3000 User's Manual
The Sensaphone SCADA 3000 is an environmental monitoring system designed to provide years of safe and reliable performance. This User's Manual, Version 2.34, covers essential safety precautions, FCC requirements, and general operating procedures. Users must read all warning labels and follow specific instructions regarding power sources, battery usage, and physical placement to prevent damage or injury.
Read onlineSensaphone SCADA 3000 specifications
| Number of Input Zones (Standard) | 16 |
|---|---|
| Maximum I/O Points (Expandable) | 144 |
| Input Types Supported | N.O./N.C. contacts, 10K Thermistors, 4-20mA Transducers |
| Number of Relay Outputs (Standard) | 8 |
| Relay Rating | 2A 120VAC/ 2A 30VDC Maximum |
| LCD Display Resolution | N/A |
| Operating Temperature Range | 32° to 158°F | 0° to 70°C |
| Operating Humidity Range | 0–90% RH non-condensing |
Source: Sensaphone SCADA 3000 Industrial Monitoring System Product Brochure
All Sensaphone SCADA 3000 documents by type
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Questions answered in these manuals
Can the system be expanded?
Yes, capabilities can be expanded by adding additional modules for more relay channels or 4-20mA analog output channels.
From: Sensaphone SCADA 3000 Industrial Monitoring System Product Brochure
What input types does the system accept?
The system accepts Normally Open (N.O.) or Normally Closed (N.C.) contacts, 10K Type Sensors (thermistors), and 4-20mA Transducers.
From: Sensaphone SCADA 3000 Industrial Monitoring System Product Brochure
What type and size of batteries are required for the SCADA 3000?
The unit requires sealed lead-acid gel cell batteries that are 12V and have a capacity between 5 and 18AH.
What is the Ringer Equivalence Number for the SCADA 3000?
The Ringer Equivalence Number assigned to the SCADA 3000 is 0.7B.
