Start here
SAMSON CO2 user manual
The Samson C02 is a pencil-style condenser microphone designed for instrument miking applications in both live performance and recording environments. It features an extended frequency response, a tight cardioid polar pattern to minimize feedback, and a rugged brass case. The unit includes a special shock-mounted mic holder and a foam wind screen.
Read onlineSamson C02 specifications
| Polar Pattern | Super-Cardioid |
|---|---|
| Frequency Response | 50~20000 Hz |
| Sensitivity | -40 dBV/Pa (10mv/Pa) |
| Rated Impedance | 2000 |
| Equivalent Noise level | 22 dB (A weighted IEC/DIN 651) |
| Max. SPL | 134 dB (THDs 0.5% 1000 Hz) |
| Dynamic Range | 112 dB |
| Power Supply | 48V Phantom Power (IEC 268-15/DIN 45596) |
| Current Consumption | 3.5 mA |
| Dimensions | 0.8" x 5.9" (20mm x 150mm) |
| Weight | 170g (6.702) |
Source: Samson C02 Studio Microphone Product Specification Sheet
All Samson C02 documents by type
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Questions answered in these manuals
What is the frequency response range of the Samson C02 microphone?
The microphone has a frequency response ranging from 50 Hz to 20,000 Hz.
From: Samson C02 Studio Microphone Product Specification Sheet
What is the maximum sound pressure level the Samson C02 can withstand?
The microphone can withstand a maximum SPL of 134 dB with 0.5% THD at 1000 Hz.
From: Samson C02 Studio Microphone Product Specification Sheet
What is the minimum load impedance required for the C02?
A minimum load impedance of 800 ohms should be used to ensure maximum signal handling capability and minimal distortion.
From: SAMSON CO2 user manual
How does the C02 handle wind noise?
The microphone has a built-in wind screen that protects against most wind and breathing noise.
From: SAMSON CO2 user manual
