Start here
Route 66 Mobile 8 Navigation User Manual
This manual describes how to use the Route 66 Mobile 8 navigation software, covering basic operation, settings, and troubleshooting. It includes information on connecting the device, using the map functions, and maintaining the software.
The document also contains reference sections such as USB connectivity, synchronization features, and help resources to assist users in getting the most out of the Mobile 8 system.
ROUTE 66 specifications
| Chipset | SiRF third‑generation low‑power Star III |
|---|---|
| Satellite Tracking | Tracks up to 20 satellites |
| Update Rate | 1 Hz |
| Power Supply | 5 V DC ±5 % |
| Battery | Rechargeable Li‑ion (primary) + 3 V backup |
| Operating Current | 75‑85 mA (continuous mode) |
| Battery Life | ≈8 hours continuous use |
| Output Interface | NMEA‑0183 V2.2 at 38400 bps |
| Position Accuracy | 5‑25 m radius (no SA code) |
All ROUTE 66 documents by type
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Questions answered in these manuals
What is the support email for Route 66 Mobile 7?
Support can be reached at [email protected].
Why is there no satellite signal?
The device may be indoors, blocked by a roof or glass, or the battery may be empty; move it outdoors, ensure the antenna has a clear view of the sky, and verify the battery LED is on.
How can I fix a Bluetooth connection failure?
Check that the Bluetooth module is properly installed and reinstall it according to section 5.2 if necessary.
