Polaroid 600/600SE Camera User Manual
This guide covers the Polaroid 600 and 600 SE pack‑film cameras, describing their interchangeable lenses, shutter speeds, aperture settings, and viewfinder operation. It explains how to attach and detach lenses, load and unload film packs, set exposure parameters, and use electronic flash units.
Maintenance procedures are included, such as lens cleaning, roller care, and handling of the caustic film developer jelly. The manual also lists available accessories and film types, helping users achieve optimal results with both color and black‑and‑white pack films.
Polaroid 600SE specifications
| Primary lens focal length | 127 mm |
|---|---|
| Secondary lens focal length (wide‑angle) | 75 mm |
| Tertiary lens focal length (portrait) | 150 mm |
| Shutter speed range | 1 sec to 1/500 sec plus B |
| Aperture range | f/4.7 to f/64 |
| Filter thread size (127 mm lens) | 55 mm |
| Print size per pack | 8.3 × 10.8 cm (3 ¼ × 4 ¼ in) |
All Polaroid 600SE documents by type
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Questions answered in these manuals
How do I attach and detach the lens on the Model 600 SE?
Insert the lens aligning the red dot on the barrel with the red dot on the camera body, turn clockwise until the dot is on top, and lock it in place; to remove, press the lens release button and turn counter‑clockwise.
How should the lens be cleaned?
Blow off dust, then gently wipe with a clean lint‑free cloth; for fingerprints use a drop of lens‑cleaning fluid and lens tissue, never silicone‑coated eyeglass tissue.
What should I do if the printer jams before printing?
Turn off the printer, open the paper tray door, remove the photo paper, reload it correctly, and close the tray.
How do I charge the battery?
Install the battery, connect the AC adapter to the printer and a power source, and charge for about 2.5 hours.
