Metcal MX-5000 Soldering, Desoldering and Rework System Configuration Guide
The Metcal MX-5000 is a high‑power soldering, desoldering and rework system designed for lead‑free, high‑mass and fine‑pitch applications. It offers increased output power, SmartHeat® process control and ergonomic hand‑pieces to improve productivity and operator comfort.
The guide describes the four available hand‑pieces (Advanced™, UltraFine™, Precision Tweezers, Desoldering), the TipSaver™ workstand with auto‑sleep power reduction, the MX‑PS5000 power supply specifications, and the extensive cartridge families (STTC, SMTC, UFTC, PTTC, STDC). Technical specifications such as input voltage, power consumption and environmental limits are listed in the final section.
OKI MX-500 specifications
| Temperature Stability | ±1.1 °C of set point |
|---|---|
| Warranty | Four‑year standard warranty |
| Calibration Requirement | No calibration needed |
Source: Metcal MX-500 Soldering, Desoldering & Rework System Product Leaflet
All OKI MX-500 documents by type
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Questions answered in these manuals
What is SmartHeat® technology?
SmartHeat® maintains a constant tip temperature by automatically adjusting power to match the thermal load, ensuring consistent soldering results.
From: Metcal MX-500 Soldering, Desoldering & Rework System Product Leaflet
Do I need to calibrate a SmartHeat® system?
No, SmartHeat® systems do not require calibration because the tip cartridge’s alloy sets the temperature automatically.
From: Metcal MX-500 Soldering, Desoldering & Rework System Product Leaflet
What is the maximum output power of the MX‑5000 system?
The MX‑5000 can deliver up to 80 W per channel when the ambient temperature is 22 °C.
From: Metcal MX-5000 Soldering, Desoldering and Rework System Configuration Guide
Which hand‑pieces are available for the MX‑5000?
Four hand‑pieces are offered: the Metcal Advanced™ hand‑piece, the Metcal UltraFine™ hand‑piece, the Precision Tweezers hand‑piece, and the Metcal Desoldering hand‑piece (MX‑DS1).
From: Metcal MX-5000 Soldering, Desoldering and Rework System Configuration Guide
