Key facts
- Brand
- Nuvoton
- Model
- NUC240
- Category
- microcontrollers
- Documents
- 2
- Languages
- EN · ZH
- Last added
- 2026-10-03
Start here
NuEdu-SDK-NUC240 User Manual
The NuEdu-SDK-NUC240 is a development kit designed for the NUC200 series microcontrollers, specifically the NUC240. It consists of two main parts: the NuEdu-EVB-NUC240 evaluation board and the NuEdu-Basic01 expansion board. The evaluation board features the NUC240VEAE chip with an ARM Cortex-M0 core running up to 72MHz, 128K Flash, and 16K SRAM. It supports various peripherals including USB 2.0, CAN, UART, SPI, I2C, and PWM. This manual is written in Chinese.
Read onlineNuvoton NUC240 specifications
| Target microcontroller | NUC240VE3AE |
|---|---|
| Reset button | SW1 on the EVB board |
| Extended connector pins | LQFP‑100 pin mapping for NUC240VE3AE |
All Nuvoton NUC240 documents by type
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Questions answered in these manuals
How is the Nu‑Link‑Me debug adaptor connected to the target board?
The adaptor connects via a USB port on the PC and a serial wired debug port on the EVB board using JP4 and JP9 connectors.
What is the core of the NUC240 microcontroller?
The NUC240 microcontroller uses an ARM Cortex-M0 core.
What is the maximum operating frequency of the NUC240?
The NUC240 can operate at a maximum frequency of 72MHz.
