Nuvoton NUC240 NuTiny SDK User Manual

The Nuvoton NuTiny‑SDK‑NUC240 user manual provides hardware setup, IDE installation, and example programs for the development board.

Brand: Nuvoton
Category: Other Electronics
Document type: User Manual
Language: English
Pages: 18
File format: PDF
File size: 1.3 MB
Published: 03 October, 2026
Updated: 03 October, 2026
MD5 checksum: 51259D7EAE4FB0D57D3C0C6FDAF3292B
PDF: Nuvoton NUC240 NuTiny SDK User Manual PDF

About this manual

The NuTiny‑SDK‑NUC240 is a development tool for the NuMicro NUC240 series, combining the NuTiny‑EVB‑NUC240 evaluation board and the Nu‑Link‑Me debug adaptor. It enables users to develop, debug, and verify applications on the NUC240VE3AE microcontroller without additional ICE hardware.

The manual covers board layout, jumper settings, connector pin assignments, and step‑by‑step instructions for using Keil μVision and IAR Embedded Workbench IDEs, including driver downloads, hardware setup, and sample programs that toggle the on‑board LED.

What's inside

Overview
Introduction
Jumper Description
Pin Assignment for Extended Connector
PCB Placement
How to Start on Keil μVision IDE
How to Start on IAR Embedded Workbench
Schematic
Download Files
Revision History

Specifications

Target microcontroller	NUC240VE3AE
Reset button	SW1 on the EVB board
Extended connector pins	LQFP‑100 pin mapping for NUC240VE3AE

Frequently asked questions

How is the Nu‑Link‑Me debug adaptor connected to the target board?

The adaptor connects via a USB port on the PC and a serial wired debug port on the EVB board using JP4 and JP9 connectors.
