Start here
Moeller EASY512-DA-RC User Manual
User Manual 7 pages · 315 KB · EN
The EASY512-DA-RC is a compact relay controller featuring four relay outputs, eight digital inputs (two usable as analog), an LCD display, and built‑in timer functions. It is designed for industrial automation and can be mounted on a top‑hat rail or fixed with screws.
The manual covers mechanical dimensions, electrical characteristics, environmental limits, and EMC compliance, helping users install, configure, and maintain the device safely and reliably.
Moeller EASY512-DA-RC specifications
| Relay outputs | 4 |
|---|---|
| Power supply voltage | 12 V DC |
| Digital inputs | 8 (2 can be used as analog inputs) |
| Dimensions (W × H × D) | 71.5 × 90 × 58 mm |
All Moeller EASY512-DA-RC documents by type
Datasheet 1
Ratings, dimensions and ordering codes, for selection and design work.
User Manual 1
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Questions answered in these manuals
How many relay outputs does the EASY512-DA-RC have?
It provides four relay outputs.
What power supply voltage is required?
The device operates from a 12 V DC supply.
