Start here
iAi CM-140 MCL CB-140 MCL Progressive Scan
The Holux GPSlim 236 Quick Guide provides step‑by‑step instructions for first‑time use. It explains how to open the battery cover, install the supplied rechargeable lithium‑ion battery, and charge the unit using the mini‑USB power cable.
The guide also covers Bluetooth pairing with a PDA, using the GPS Viewer software, and safety warnings such as avoiding prolonged exposure to strong sunlight. Contact information for Holux Technology Inc. is listed at the end of the document.
iAi CB-140 specifications
| Sensor type | 1/3" progressive scan CCD |
|---|---|
| Pixel clock | 40 MHz |
| Full‑frame rate | 90.5 fps |
| Active area | 4.9 mm × 3.7 mm |
| Pixel size | 7.4 µm × 7.4 µm |
| Resolution | 656 × 494 pixels (full) |
| Video output | GigE Vision, 8‑bit or 10‑bit |
| Power consumption | 12 V DC, 3.6 W |
| Operating temperature | -5 °C to +45 °C |
| Dimensions (H×W×L) | 29 mm × 44 mm × 75 mm |
| Weight | 125 g |
All iAi CB-140 documents by type
Ratings, dimensions and ordering codes, for selection and design work.
The shortest path to a working setup, usually only a few pages.
Questions answered in these manuals
What is the maximum frame rate for full‑frame capture?
The camera can capture up to 90.5 frames per second at full resolution.
Which interface does the camera use for data transfer?
It uses a GigE Vision interface with an RJ‑45 connector, supporting 8‑ or 10‑bit output.
How do you open the battery cover on the GPSlim 236?
Hold the device with one hand, place the index finger on the extended notch, and press down to release the cover.
What is the default Bluetooth passkey for the GPSlim 236?
The default Bluetooth passkey is 0000.
