Specification sheet for Yageo AC Series automotive‑grade thick‑film chip resistors covering sizes 0201‑2512.
The Yageo AC Series datasheet provides detailed product specifications for automotive‑grade thick‑film chip resistors ranging from 0201 to 2512. It includes ordering information, marking rules, construction details, dimensions, power characteristics, functional description, packaging options, and test requirements.
The document also lists the environmental compliance (RoHS, halogen‑free), AEC‑Q200 qualification, and legal disclaimer. All data are presented for each size and tolerance option, with tables for resistance coding, dimensions, and electrical performance.
| Rated Power (AC0805) | 1/8 W (0.125 W) |
|---|---|
| Tolerance Options | ±5 %, ±1 %, ±0.5 % |
The AC series resistors are offered with ±5 %, ±1 % and ±0.5 % tolerance options.
Yes, all AC series resistors are RoHS compliant and halogen‑free.
