Siemens Comfort Panel TP1500 Download Operation Guide

About this manual

This document serves as a reference guide for downloading projects to the Siemens new-generation Comfort Panel series, specifically focusing on the TP1500 model. It covers various communication interfaces including MPI, PROFIBUS, Ethernet (PN/IE), and USB.

The guide provides step-by-step instructions for configuring settings on both the HMI panel and the engineering computer. It details requirements such as necessary CP cards or adapters, cable connections, and parameter configurations like baud rates and station addresses to ensure successful data transfer using TIA Portal software. This manual is written in Chinese.

What's inside

• Introduction
• MPI Download Method
• PROFIBUS Download Method
• Ethernet and PN/IE Download Method
• USB Download Method
• OS Update

Frequently asked questions

What software version is required to configure the Comfort Panel?

Configuration requires WinCC Comfort V11 SP2 or a later version.

What transmission rate is used for the MPI download example?

The example uses a transmission rate of 187.5 kbits/s.

Which CP card does the guide use as an example for MPI downloads?

The guide uses the PC Adapter USB A2 adapter as its example.
