This Siemens TIP application handbook details integrated energy management solutions for medical facility power distribution systems.
The handbook provides a comprehensive guide to totally integrated power (TIP) solutions for hospitals and other medical facilities. It covers planning trends, power demand analysis, supply architecture, special power‑supply design, grid modelling with SIMARIS, and the design and configuration of major distribution components.
Key sections include dedicated power‑supply design for specialized areas, hospital power‑supply architecture, experience‑based power‑demand values, SIMARIS grid models, and detailed component specifications such as transformers, switchgear, busbars, and distribution cabinets. Appendices list reference standards and further reading. This manual is written in Chinese.
| NPS power demand per bed | 0.9 to 3.8 kW/bed |
|---|---|
| SPS power demand per bed | 0.45 to 1.9 kW/bed |
| MAGNETOM C! MRI load | ≈15 kVA |
| MAGNETOM ESSENZA MRI load | ≈45 kVA |
| MAGNETOM Skyra MRI load | ≈110 kVA |
NPS demand ranges from 0.9 to 3.8 kW per bed, while SPS demand ranges from 0.45 to 1.9 kW per bed.
The guide recommends using dedicated medium‑voltage power supplies with independent transformers and low‑voltage distribution for high‑performance imaging rooms.
