Siemens KTP600 Basic color DP Operation Guide

This guide details download methods (PPI, MPI, DP, Ethernet) and OS update procedures for the Siemens KTP600 Basic color DP panel.

Brand: Siemens
Category: Industrial Robot
Document type: User Manual
Language: Chinese
Pages: 60
File format: PDF
File size: 2.7 MB
Published: 16 October, 2026
Updated: 16 October, 2026
MD5 checksum: B9E5B7386863AA1213678E4704FA6E9F
PDF: Siemens KTP600 Basic color DP Operation Guide PDF

About this manual

This manual provides instructions for downloading projects to the Siemens KTP600 Basic color DP operator panel using various communication protocols, including PPI, MPI, DP, and Ethernet. It covers specific settings required on the panel, the configuration cable, and the WinCC (TIA Portal) software. This manual is written in Chinese.

What's inside

PPI Download Method
MPI Download Method
DP Download Method
Ethernet Download Method
OS Update Settings
Factory Reset
Cable Configuration
Software Settings

Specifications

RS232/PPI Cable Part Number	6ES7901-3CB30-0XA0
USB/PPI Cable Part Number	6ES7901-3DB30-0XA0

Frequently asked questions

Which cables are required for PPI download on KTP600 Basic color DP?

You need an RS232/PPI cable (6ES7901-3CB30-0XA0) or a USB/PPI cable (6ES7901-3DB30-0XA0).

What should I do if I need to reset the panel to factory settings during an OS update?

Check the 'Restore to factory settings' box and enter the panel's MAC address found on the back of the device.

Download PDF (2.7 MB)
