Siemens SINUMERIK 840D/840Di/810D Programming Manual – Work Preparation Section

About this manual

The document is a programming guide aimed at machine‑tool users who need to set up and program Siemens SINUMERIK 840D, 840Di or 810D CNC controllers. It explains the required information and procedures for preparing the control system for production.

The manual is organized into sections such as Subprogram Technology, Macro Instruction Technology, File and Program Management, Protection Areas, Special Displacement Instructions, Framework, Conversion, Tool Compensation, Trajectory Displacement Performance, Synchronous Motion, Swing, Punching and Peck, Other Functions, Independent Cutting Programs and Tables. It also includes a quick‑reference index and contact information for technical support. This manual is written in Chinese.

What's inside

• Subprogram Technology
• Macro Instruction Technology
• File and Program Management
• Protection Areas
• Special Displacement Instructions
• Tool Compensation
• Trajectory Displacement Performance
• Synchronous Motion
• Swing
• Punching and Peck

Specifications

Frequently asked questions

What is the purpose of this manual?

It provides programming instructions for the work‑preparation part of SINUMERIK 840D/840Di/810D control systems.

How can I obtain technical support for this manual?

Contact the A&D technical support hotline at +49 (0) 180 5050‑222 or email [email protected].
