Sapphire Pure Platinum A75M Motherboard Installation Manual

About this manual

This manual provides instructions for installing the Sapphire Pure Platinum A75M motherboard. It details the physical layout of the board, including I/O ports, expansion slots, and internal connectors such as power and SATA interfaces.

The guide covers step-by-step hardware installation procedures, from preparing the chassis to mounting the CPU, memory modules, and expansion cards. Additionally, it includes instructions for configuring the BIOS settings and installing necessary device drivers. This manual is written in Chinese.

What's inside

• Introduction
• Motherboard Layout
• I/O Back Panel
• Installation Preparation
• Installing I/O Shield
• Mounting Motherboard to Chassis
• CPU Installation
• Memory Installation
• Expansion Card Installation
• Cable Connections

Frequently asked questions

What type of processor socket does this motherboard use?

The motherboard uses an AMD FM1 processor interface.

How many SATA 3.0 interfaces are available on the board?

There are six SATA 3.0 interfaces provided for storage connections.

What is the maximum data transfer rate of the SATA cables?

The SATA cables support a working speed up to 6Gb/s.
