The Olympus LEXT OLS4000 user manual explains features, measurement modes, specifications, and operation steps for the 3D measurement laser microscope.
This manual introduces the LEXT OLS4000 3D measurement laser microscope, highlighting its high‑resolution short‑wavelength laser source, dual confocal optical system, and various measurement modes such as surface roughness, area/volume, particle, geometry, and film‑thickness. It also describes the built‑in hybrid damping mechanism that allows stable measurements on a regular desk.
The document provides guidance on using the guided operation interface, ID‑based user management, report generation, and detailed technical specifications, including optical zoom ranges, light source types, and measurement accuracy figures. This manual is written in Chinese.
| Light source wavelength | 405 nm |
|---|---|
| Maximum optical magnification | 108x‑17280x |
| Measurement repeatability (100x) | ±0.02 µm |
| Height measurement accuracy | ±0.2 µm + L/100 µm |
| XY stage travel range | 100 mm × 100 mm |
It provides seven measurement modes, including surface roughness, area/volume, particle, geometry, film‑thickness, automatic edge detection, and 3D observation.
The laser beam measures surface roughness without touching the sample, avoiding damage to soft or sticky specimens.
Yes, its built‑in hybrid damping mechanism allows stable measurements on ordinary tables.
After measurement, a single click creates a report, and the built‑in editor lets users customize report templates.
