This manual provides installation, configuration, and troubleshooting instructions for the Norco MATX-6983 motherboard based on the Hygon 3100 series…
The Norco MATX-6983 is a motherboard designed for industrial automation, POS terminals, and multi-display applications. It is built on the domestic Hygon 3100 series AMD X86 architecture and supports various Hygon C86 processors, including the 3188, 3185, and 3138 models. The board features a rich array of interfaces, including 10 serial ports, 4 USB 3.0 ports, 4 SATA 3.0 ports, dual VGA, and HDMI display outputs. This manual is written in Chinese.
| Processor Support | Hygon 3100 series (3188, 3185, 3138, 3135, 3131E, 3180) |
|---|---|
| Chipset | Hygon C86 series |
| Memory Support | Dual channel 4x DDR4 UDIMM, max 512GB |
| USB Ports | 4x USB 3.0, 5x USB 2.0 |
| SATA Ports | 4x SATA 3.0 |
| Video Outputs | 2x VGA, 1x HDMI |
| Network Interfaces | 2x Gigabit RJ45 |
| Dimensions | 244mm x 244mm |
It supports Hygon C86 processors including the 3188, 3185, 3138, 3135, 3131E, and 3180.
The board supports a maximum of 512GB using four DDR4 UDIMM slots.
The motherboard provides two standard DB15 VGA interfaces and one HDMI interface.
