Quick start guide for the Motorola LI4278 Linear Imager barcode scanner, covering setup, connection, battery handling, safety and troubleshooting.
This guide provides step‑by‑step instructions for getting the LI4278 Linear Imager up and running. It covers cradle cable connections, host interface selection, default settings, and Bluetooth or USB configuration. Battery preparation, charging procedures, and ergonomic safety recommendations are also included.
Additional sections address LED and beeper status indicators, regulatory compliance, battery care, and troubleshooting tips for common error conditions such as low battery, transmission errors, and connection problems. Warranty and support information are provided at the end of the document.
| Optical Output | 0.87 mW |
|---|---|
| Emitted Wavelength | 590‑650 nm |
| Bluetooth Max Radiated Power | 100 mW EIRP |
| Battery Charging Temperature Range | +32 °F to +104 °F (0 °C to +40 °C) |
Charge the linear imager scanner for 24 hours before the first full day of use.
A green LED means the scanner is ready to scan, is charging, or indicates a successful barcode decode.
Turn the battery off and select the “Return to factory defaults” option.
