This manual provides safety, installation, wiring and operation instructions for the Mitsubishi CC-Link IE field network analog‑digital conversion module.
The manual begins with safety warnings, describing symbols such as "/人警告" that indicate hazards which could cause death or serious injury. It stresses the need to disconnect all external power sources before any installation or wiring work.
Installation and wiring sections detail proper handling of terminal blocks, required grounding, and the maximum number of installation cycles (50). The document also lists the module’s I/O assignments, such as near‑end input signals (RXO‑RX1F) and output signals (RYO‑RYTF), and provides troubleshooting guidance. This manual is written in Chinese.
| Near‑end input signal | RXO - RX1F |
|---|---|
| Near‑end output signal | RYO - RYTF |
| Near‑end register | RWO - RWF |
| Maximum terminal‑block installation cycles | 50 |
The terminal block may be installed no more than 50 times.
A distance of at least 100 m should be maintained.
All external power sources must be completely disconnected before any wiring work.
