Leica TS16 Total Station User Manual

About this manual

This document serves as the official user manual for the Leica TS16 total station, covering essential safety directions, system descriptions, and operational procedures. It includes instructions for setting up the instrument, SmartStation, and SmartPole, as well as connecting to external devices like personal computers and tablets.

The manual also details the user interface, including keyboard operation and LED indicators, and provides comprehensive guidelines for achieving correct measurement results. Furthermore, it outlines procedures for checking and adjusting the instrument, maintaining the tripod, and transporting or storing the equipment safely.

What's inside

• Safety Directions
• Description of the System
• User Interface
• Operation
• Setting Up the TS Instrument
• Setting Up SmartStation
• Setting Up SmartPole
• Power Functions
• Batteries
• Check & Adjust

Specifications

Frequently asked questions

What signal words are used in the safety messages?

The manual uses DANGER, WARNING, CAUTION, and NOTICE as standardised signal words to identify levels of hazards and risks.

What are the intended uses of the Leica TS16?

The instrument is intended for measuring horizontal and vertical angles, measuring distances, recording measurements, capturing and recording images, and remote control of the product.

What safety signal words are used in the manual?

The manual uses DANGER, WARNING, CAUTION, and NOTICE as standardised signal words to identify levels of hazards and risks.

What is the manufacturer of the TS16?

The manufacturer is Leica Geosystems AG, located in Heerbrugg, Switzerland.
