About this manual

This document is the user manual for the Leica Geosystems TS09plus L total station, a product designed to meet Chinese surveying needs with Swiss optical and mechanical technology. It highlights key features such as 1" angular accuracy, a 1000m non-prism range with PinPoint technology, and a standard digital keypad to avoid touch screen errors. The manual also details the included communication side cover with USB and Bluetooth support. This manual is written in Chinese.

What's inside

Product Features
Applications
Technical Specifications
Data Storage & Transmission
Anti-Counterfeit Measures
After-Sales Service

Specifications

Prism Distance Range	3500m
Non-Prism Range	>1000m
Telescope Magnification	30×
Operating System	Windows CE 5.0 Core
Battery Operation Time	30 hours
Weight	5.1kg

Frequently asked questions

What is the angular accuracy of the TS09plus L?

The instrument offers 1" angular accuracy.

Does the TS09plus L support non-prism measurement?

Yes, it uses PinPoint technology with a range of over 1000m.

What operating system does the TS09plus L run on?

It runs on Windows CE 5.0 Core.
