Janitza UMG511 User Manual

This manual covers the installation, operation, programming, and technical specifications of the Janitza UMG511 power quality analyzer.

Brand: Janitza
Document type: User Manual
Language: German
Pages: 76
File format: PDF
File size: 1.1 MB
Published: 12 October, 2026
Updated: 12 October, 2026
MD5 checksum: 957BE23C419E71B586B56C065352AD52
PDF: Janitza UMG511 User Manual PDF

About this manual

The Janitza UMG511 is a device designed to measure voltage quality in building equipment according to EN61000-4-30. It measures voltage and current from the same grid and is suitable for installation in fixed, weather-resistant control panels. The device supports 2, 3, and 4-wire networks as well as TN and TT systems. This manual is written in German.

What's inside

Overview
Description
Measurement Process
Programming Software GridVis
Control Operation
Assembly
Installation
Power Supply Voltage
Voltage Measurement
Current Measurement

Specifications

SDRAM Memory	32 Mbyte

Frequently asked questions

What is the UMG511 used for?

The UMG511 is used to measure the quality of voltage delivered to distribution boards, circuit breakers, and busbars in building equipment.

What is the required mounting size for the device?

The device requires a front panel installation opening of 144x144mm.

What is the operating temperature range?

The device operates within a temperature range of -10℃ to +55℃.
