User manual for Inovance MD050 series Active Front End (AFE) covering safety, installation, configuration, troubleshooting and warranty.
The MD050 series Active Front End (AFE) unit converts motor braking energy and feeds it back to the grid, offering over‑95% regeneration efficiency, low noise, low harmonic distortion and built‑in over‑temperature, over‑voltage and over‑current protection. This manual provides detailed information on product features, selection, parameter settings, commissioning, operation and maintenance.
Key sections include safety precautions, product specifications, mechanical and electrical installation, simple system debugging, operation display, functional parameter tables, fault diagnosis and appendices such as communication protocol details and version change records. The warranty terms and service contact information are also provided. This manual is written in Chinese.
| MD050‑T37G rated power | 58 kW |
|---|---|
| MD050‑T55G rated power | 86 kW |
| Warranty period | 18 months |
The product has an 18‑month warranty, provided the unit is used according to the manual.
