Inovance GVD570-P3R3L1R5LLL Onboard Charger Manual

Official manual for the Inovance GVD570-P3R3L1R5LLL onboard charger covering features, specifications, installation and protection functions.

Inovance GVD570-P3R3L1R5LLL Onboard Charger Manual - cover page
Brand
Inovance
Category
Vehicle Accessories
Document type
User Manual
Language
Chinese
Pages
10
File format
PDF
File size
1.3 MB
Published
29 September, 2026
Updated
29 September, 2026
MD5 checksum
267627A7D314724BC42106D57B6DB6D7
PDF
Inovance GVD570-P3R3L1R5LLL Onboard Charger Manual PDF

About this manual

The manual introduces the Inovance GVD570-P3R3L1R5LLL onboard charger (OBC) and its integrated DC‑DC converter, highlighting its compact design, water‑cooled system, and high power density for passenger vehicles. It details the product’s certifications, protection functions, and environmental specifications.

Technical sections provide detailed electrical parameters, cooling method, protection ratings, dimensions, and weight, as well as guidance for system design, installation, and troubleshooting. The document also lists applicable vehicle types and application scenarios. This manual is written in Chinese.

What's inside

  • Company Overview
  • Why Choose Inovance
  • Product Introduction
  • Technical Specifications
  • Protection Functions
  • Cooling Method
  • Installation and Commissioning
  • Application Scenarios
  • Safety and Certification

Specifications

Input voltage (AC)220V AC ±15%
Input voltage (DC)200‑430VDC
Maximum output power (OBC)3.3 kW
Download PDF (1.3 MB)
