The IMB MB5015A automatic thread collector user manual provides setup, operation, safety, wiring, maintenance, and troubleshooting information.
This manual covers the IMB MB5015A automatic thread collector, an industrial sewing machine accessory. It includes basic device information, technical parameters, safety precautions, button functions, operation steps, electrical wiring, common issues, and daily maintenance requirements.
Users are guided through preparation, power‑on, reset, task selection, feeding, and auxiliary functions such as threading and XY zeroing. The document also details safety rules, wiring diagrams, and a troubleshooting guide for position offsets and needle breakage. This manual is written in Chinese.
| Machine head configuration | JUKI-DDL-9000C |
|---|---|
| Maximum sewing speed | 4000 rpm |
| Operating voltage | 220 V |
| Operating air pressure | 0.5 MPa |
| Stitch length range | 1~6 mm |
| Needle model | DBX1*DBX5(#11)#9~18 (Num65~110) |
| Working efficiency | 13 seconds per piece |
| Device weight | 75 kg |
| Device dimensions | 1704 L × 1002 W × 1250 H mm |
| Number of thread saving types | 4 |
| Maximum thread saving length | 230 mm |
| Thread saving styles | Straight, diagonal, corner, round‑corner |
Press the reset button on the touchscreen after confirming the needle path is clear; the needle and X/Y mechanisms will move to their zero positions.
