Official user manual for the Icom IC-A24/A6 VHF Air Band Transceiver with safety, operation, and specifications.
The Icom IC-A24/A6 VHF Air Band Transceiver manual provides detailed safety training, operating instructions, and accessory information for occupational use. It includes warnings about RF exposure, proper antenna use, and handling of battery packs.
The document also contains a full table of contents covering panel description, basic operation, memory and scan functions, VOR navigation (IC-A24 only), battery charging, cloning, troubleshooting, specifications, and quick reference guides.
| Transmit frequency coverage | 118.000 to 136.975 MHz |
|---|---|
| Receive frequency coverage | 108.000 to 136.975 MHz |
| Channel spacing | 25 kHz |
| Number of memory channels | 200 (20 CH × 10 BANK) |
| Usable temperature range | –10 °C to +60 °C |
| Typical output power | 5 W (PEP) typical |
| Antenna connector | BNC 50 Ω |
| Dimensions (W × H × D) | 54 mm × 129.3 mm × 35.5 mm |
| Weight | ≈180 g (without battery pack and antenna) |
The typical peak envelope power is 5 W.
It operates safely from –10 °C to +60 °C.
The unit offers 200 memory channels, organized as 20 channels per bank across 10 banks.
