HLP SK Series Air Compressor Vector Inverter User Manual

This manual covers the installation, operation, parameter settings, fault diagnosis, and maintenance of HLP SK series vector inverters designed for air…

Brand: HLP
Document type: User Manual
Language: Chinese
Pages: 263
File format: PDF
File size: 13.9 MB
Published: 24 October, 2026
Updated: 24 October, 2026
MD5 checksum: F6D16A211D78506ED2EB51520A0A7664
PDF: HLP SK Series Air Compressor Vector Inverter User Manual PDF

About this manual

The document is a comprehensive user guide for the HLP SK series of vector inverters specifically engineered for air compressor applications. It details safety precautions, product specifications for various sub-series (SK190, SK200, SK300), and provides instructions for mechanical and electrical installation. This manual is written in Chinese.

What's inside

Safety Precautions
Product Specifications
Mechanical Installation
Electrical Wiring
Operation & Display
Parameter Settings
Fault Alarms
Maintenance

Specifications

Input Voltage (3-phase)	Three-phase 380~480V -20%~+10%
Output Frequency	0~400Hz
Control Modes	V/F, Vector Control
Overload Capacity (60s)	150% rated output current
