This manual provides operating instructions for the Gustard H16 headphone amplifier, covering panel controls, remote usage, balanced connections, and…
The Gustard H16 is a high-resolution headphone amplifier featuring an OLED display and rotary knob for volume and menu navigation. It supports multiple input channels including XLR and RCA, with adjustable gain settings ranging from Low to High. The device includes an infrared remote control for convenient operation of mute, volume, and menu functions. This manual is written in Chinese.
| Frequency Response (Preamp Output) | 20-80kHz /-0.1dB |
|---|---|
| Signal-to-Noise Ratio (Preamp Output) | 120dB |
| Total Harmonic Distortion + Noise | <0.0004% |
| Max Undistorted Power (Balanced, 64Ω) | 3700mW |
| Power Supply | AC 115V/230V 50/60Hz |
| Dimensions (WxHxD) | 220mm * 50mm * 170mm |
Operate the rotary knob directly when the screen shows the main page; counter-clockwise decreases and clockwise increases volume.
The amplifier offers three adjustable gain levels: Low, Mid, and High.
Gustard provides a free warranty service of 2 years from the purchase date, with lifetime maintenance.
