This is the user manual for the Feiyu V2.2 three-axis gimbal, covering installation, operation modes, balancing, and charging instructions.
This manual provides instructions for the Feiyu V2.2 three-axis gimbal designed for micro single cameras. It covers product overview, installation of the camera and batteries, and basic operation including power on/off procedures. The guide details various control modes such as follow mode, lock mode, and auto-rotation, along with joystick and trigger key functions.
The document also explains how to balance the gimbal on the pitch, roll, and yaw axes to ensure stable performance. It includes sections on charging the 18650 batteries, using the shutter button for photography, and interpreting status indicator lights. Finally, it lists safety warnings and provides the official website for firmware updates and further information. This manual is written in Chinese.
The device requires two 18650 batteries installed inside the handle.
The default rotation speed is set to 1 hour per revolution.
The red light will flash three times every five seconds, indicating you should charge or replace the batteries.
