A comprehensive guide to Fairchild Semiconductor's standard product lineup, covering bridge rectifiers, JFETs, MOSFETs, diodes, transistors and more.
The Standard Products Guide presents Fairchild Semiconductor's broad range of discrete semiconductor devices. It includes performance data, part numbers and key electrical characteristics for each product family.
The guide is organized by device type – bridge rectifiers, junction FETs, MOSFETs, power BJTs, Schottky diodes, small‑signal diodes, transient voltage suppressors, Zener diodes, linear devices, comparators, LDOs, op‑amps, regulators, timers, voltage detectors, stabilizers, voltage‑to‑frequency converters – and provides packaging information for surface‑mount and thru‑hole options.
| Maximum Repetitive Reverse Voltage (VRRM) | 50 V (DF005M) |
|---|---|
| Average Forward Current (IF(AV)) | 1.5 A (DF005M) |
| Maximum Instantaneous Forward Voltage (VFM) | 1.1 V (DF005M) |
