Chinese user manual for the Delixi EM60 variable‑frequency drive covering safety, installation, operation, parameters and troubleshooting.
The manual begins with safety warnings and acceptance checks, emphasizing that installation and maintenance must be performed by qualified personnel. It lists the required inspections of the unit, name‑plate data, and provides guidance on handling, storage and transport.
Subsequent sections detail product specifications, wiring diagrams, keyboard operation, functional parameter tables, common functions such as start‑stop control, PID, and RS‑485 communication, and a comprehensive fault‑diagnosis guide. Appendices describe the optional EM60 expansion cards and their I/O configurations. This manual is written in Chinese.
| Control method | V/F control, Open‑loop vector control (SVC) |
|---|---|
| Frequency accuracy (digital) | 0.02 % |
| Overload capacity | 150 % rated current for 60 s, 180 % rated current for 3 s |
| Maximum output current | 300 mA |
The drive tolerates 150 % of its rated current for 60 seconds and 180 % for 3 seconds before triggering overload protection.
