This manual describes the CDI‑BR series energy braking units, which are used with inverters in elevators, hoists, mining lifts, centrifuges, oil‑field pumps and other applications. It explains how the unit dissipates regenerated energy as heat to provide braking torque and ensure safe operation of the drive system.
The document covers product specifications, terminal layout, wiring diagrams, installation dimensions, main‑circuit connection methods, cable sizing, and a troubleshooting guide with error codes and common fault remedies. This manual is written in Chinese.
| Rated voltage | 三相380V |
|---|---|
| Grid frequency | 45~65Hz |
| Braking method | 自动电压跟踪方式 |
| Overheat protection temperature | 80°C |
| Maximum humidity | ≤90% RH |
| Maximum vibration | ≤0.5g |
Connect DC+ and DC- to the inverter’s DC bus positive and negative terminals, keeping the cable length as short as possible.
The unit includes overheat and overcurrent protection.
