The Bose Panaray LT6400 is a mid‑high frequency loudspeaker designed for professional audio installations. This leaflet provides the acoustic performance data, electrical interface details, and physical characteristics needed for system integration.
Key features include a 100 W power handling capability, 8 Ω nominal impedance, 100 dB SPL sensitivity, and a frequency response of 200 Hz – 16 kHz. The speaker’s 10‑layer enclosure offers 16 stainless‑steel suspension points and dimensions of 574 mm × 640 mm × 612 mm, making it suitable for a variety of mounting configurations. The document also outlines safety compliance, warranty terms, and available replacement parts. This manual is written in Chinese.
| Power handling | 100 W |
|---|---|
| Sensitivity (1 W @ 1 m) | 100 dB SPL |
| Maximum SPL (pink noise @ 1 m) | 120 dB SPL |
| Peak SPL | 126 dB SPL |
| Frequency response | 200 Hz – 16 kHz (±3 dB) |
| Dimensions (W × H × D) | 574 mm × 640 mm × 612 mm |
| Weight | 36.29 kg |
| Transport weight | 46.27 kg |
The LT6400 can handle up to 100 W of power.
The speaker is covered by a 5‑year warranty.
Mounting points use SAE 3/8‑16 threads with at least 18 threads provided for use.
