This manual explains installation, wiring, operation, maintenance and safety for the Azbil AUR350C advanced UV controller with communication function.
The Azbil AUR350C UV Controller User Manual provides detailed instructions for safe installation, correct wiring, and proper operation of the advanced UV controller. It includes safety warnings, grounding requirements, and procedures for testing and maintenance.
Key sections cover safety precautions, mechanical installation, wiring diagrams, RS‑485 communication setup, CPL communication features, test‑run adjustments, and specifications of terminals and relays. The document also references related manuals for sensors and programming software. This manual is written in Chinese.
| Power Supply Voltage | 100/200VAC 50/60Hz |
|---|---|
| Grounding Resistance Requirement | ≤ 100Ω |
| Relay Output K3 Rating | 3A 250V (cos φ =1) |
| Relay Output K2 Rating | 5A 250V (cos φ =1) |
| Maximum Connected Devices (RS‑485) | 15 devices |
The controller can be connected to up to 15 devices on the RS‑485 bus.
The grounding resistance must be 100 Ω or less.
Power must be turned off, terminals should not be touched, and proper grounding must be ensured before any wiring or installation work.
The K3 relay output is rated for 3 A at 250 V (cos φ = 1).
