The Avid System 5 User Guide provides hardware overview, startup sequence, system requirements, and detailed instructions for using eMix and the system modules.
The System 5 is a modular digital audio mixing system designed for professional audio production. Its control surface connects to processing cores via Ethernet, while audio passes through dedicated I/O units. The guide introduces the hardware architecture, system startup, and required system specifications.
The manual covers common tasks such as connecting microphones and CD playback, detailed operation of the eMix application, and configuration of modules like the CM401T Master Section and CM402T Expanded Channel Module. Safety, compliance, and service information are also provided.
| DF66 DSP line cards | Maximum of six 120 MHz DSP line cards |
|---|---|
| DF70 DSP line cards | Maximum of eight 120 MHz DSP cards |
| Audio I/O interface | MADI |
| Power supply voltage | 120 V AC input only |
| Maximum ambient temperature | 40 °C |
The System 5 uses a power supply cord set suitable for 120 V AC input only.
The DF66 core can accommodate up to six 120 MHz DSP line cards.
