The Avid Mbox 8.0.4 User Manual provides installation, configuration, hardware overview, and usage instructions for Mac and Windows systems.
The Avid Mbox is an audio and MIDI production system that offers two analog inputs and outputs, digital I/O, MIDI ports, and high‑resolution conversion. This manual explains how to set up and operate the device, covering both hardware features and software integration with Pro Tools LE.
Key sections include installation procedures for Mac and Windows, detailed hardware connection guides, system configuration steps, troubleshooting tips, and references to online resources. Appendices provide driver control panel details, multi‑function button usage, AMS and MIDI studio configuration, hard‑disk maintenance, and additional resources.
| Analog audio inputs and outputs | 2 inputs, 2 outputs |
|---|---|
| Digital audio inputs and outputs | 2 inputs, 2 outputs |
| MIDI input and output ports | 16 in, 16 out |
| A/D and D/A converter resolution | 24‑bit / 96 kHz |
| USB interface | USB 2.0 high‑speed |
| Phantom power | 48 V |
The Mbox works with both Mac and Windows systems.
It provides 16 MIDI input channels and 16 MIDI output channels.
No, an unpowered hub will not work; use an active hub or a dedicated USB port.
